Auto Idle: Idles the engine when machine functions are not used for four seconds or more; throttle returns to previous position when joystick is moved or travel function is engaged.
Auto Shift Travel: Transitions the drive motors to and from high range during travel; provides on-demand travel performance with no manual shifting.
Selectable Control Pattern: Easily change between “excavator” and “backhoe” control pattern.
Conventional Tail Swing: Offers top lift capacity and better access through doors or crowded yards.
Angle Blade (optional): Places spoil accurately with simultaneious up/down and angle adjustments, up to 25 degrees left or right; bolt on, reversible cutting edge provides long life and easy replacement.
Piston Pump and Closed Center Valve System: Senses loads, delivers smooth control and provides exceptional metering.
Hydraulic System: Provides smooth, refined operation for tough jobs.
Selectable Auxiliary Hydraulic Flow: Operator can elect one of three flow rates to optimize the response of particular hydraulic attachments such as maximum flow for attachments like the auger, medium flow for slower clamp movements and lowest flow for precise movements of a Power Tilt accessory.
Fingertip Swing Control: Rocker-style thumb switch improves metering of the swing function and provides more floor space.
Quick Couplers: Keeps auxiliary quick couplers in convenient location on the boom, but out of the trench and out of harm’s way.
Easy Hydraulic Clamp Installation: Simplify installation of a hydraulic clamp through an auxiliary port relief on the closed center valve. Clamp mounts integrated into the dipper arm.
X-Change System (standard): Allows you to change attachments quickly with Bobcat’s exclusive system.
Hydraulic X-Change (optional): The most convenient attachment chagnes in the industry. Enables fast attachment changes through a switch that activates hydraulic pins for attachment removal or hook-up.
Dual Direction Detent: Standard feature that provides continuous flow for attachments.
Blade Float: Simplify grading, leveling and backfilling. Smoothly finish your work with minimal operator input using the blade float.
Operating weight: 4194kg
Dig depth: 3200mm
Max power: 31.2kW
Engine E42
Emissions Tier (EPA) Interim Tier 4
Engine Fuel Diesel Diesel
Maximum Governed RPM 2200 RPM
Horsepower 41.8 HP 41.8 HP
Turbocharged Engine No
Performance E42
Operating Weight 9246 lbs
Weight Class 4.2 t 4.4 t
Travel Speed - High 2.9 mph
Travel Speed - Low 1.5 1.6 mph
Arm Digging Force 5778 lbf
Bucket Digging Force 9105 lbf 91
Rated Lift Capacity 4603 lbs
Lift Radius 118 in 118 in
Boom Swing - Left 75 deg
Boom Swing - Right 50 deg 50 deg
Maximum Dig Depth 10.5 ft
Max Dump Height 12.2 ft 12.8 ft
Maximum Reach at Ground Level 17.3 ft
Capacities
E42
Fuel Tank 21.1 gal l
Hydraulic System
E42
Auxiliary Std Flow 20 GPM
Auxiliary Pressure 3045 psi 3045 psi
Dimension
E42
Length
200 in
Overall Length in Travel Position 200 in 201.6 in
Width 68.9 in
Height 98.7 in 98.7 in
Height with Operator Cab 98.7 in
