Packserv 3M Top & Bottom Case Sealer Bottom Drive * up to 40 cases / min * - Hire

The 3M-Matic Case Sealer 200a with 3M AccuGlide-3 taping heads is designed to seal the top and bottom center seams of up to 40 uniform regular slotted containers per minute. A heavy duty gear motor provides power to the bottom belt drive, and adjustable side and top guides position and align your boxes for quick and easy throughput.


Weight 270kg (approx.)
Machine Height 530mm-860mm (adjustable)
Machine Width 927mm
Power Supply 240V 10Amp power
Operating Speed Up to 40 boxes/minute
Drive Belt Speed 0.5m/s
Box Lengths 150mm+
Box Widths 114mm-546mm
Box Heights 121mm-622mm
Box Weights 1kg-38kg

- Automatic Function
- Seals up to 40 uniform cases per minute
- Quick, easy adjustments allow for a wide range of case heights and widths
- 3M AccuGlide 3 Taping Heads apply a “C” clip of 2? Scotch box sealing tape to both top and bottom of cases
- Compression rollers squeeze flaps together to create a tight center seam
- Durable bottom belt drive offers workhorse dependability for cases weighing up to 85 pounds
- Dual masts and dual crossbars for taping head stability
- Centrally-located emergency stop for quick and easy access
- Features infeed and exit conveyors

Mounting:
Frame featuring castors
