SKU: EH140B
• Operating pressure: 160-180kg/cm² (2272-2556 psi / 157-177 bar)
• Hydraulic flow range: 120-180l/min (31.7-47.6gal/min)
• Impact frequency 350-550bpm
• Impact Energy 3900-4100J
• Diameter of hose: 25.4mm/1inch
• Diameter of Tool 140mm/5.51inch
• Weight of Tool 135kg
• Suitable Carrier: 0.7-0.9m³
• Suitable Carrier: 18-26ton
• Valve Type: Inward
• Accumulator exists: Yes
Shipping Specs:
• Body Weight: 956kg (2103lb)
• Total weight: 2230 kg
• Length: 86.6 in
• Width: 31.5 in
• Height: 39.4 in
Compatible Models
• CAT: 80mm Pin Excavators 308B, 318C, 319D, 319E, 320B, 320C, 320D, 320E, 320F, 321B, 321C, 321D, 323F, 325F, M318D, M320F, M322D, M322F
• Atlas: 1702, 1804 Excavators
• Case: 9021, CX160, CX210, CX210B, CX225SR Excavators
• Daewoo: Solar 170LC-V, Solar 170W-3, Solar 200W-3, Solar 220LC-V Excavators
• Hitachi: EX150, EX150-1, EX150-2, EX150-3, EX150-4, EX150-5, EX160, EX160-5, EX165, EX200, EX200-5, EX215, FH165, FH200, FH215, ZX160, ZX160-3, ZX160-5, ZX180W, ZX190W-3, ZX190W-5, ZX200, ZX200-3, ZX200LC, ZX210, ZX210-5, ZX210W, ZX220W-3, ZX225RTS, ZX225US LC, ZX225USL, ZX225USR, ZX245LC-5 Excavators
• JCB: JS150LC, JS160, JS160LC, JS180, JS200, JS200LC, JS210, JS220, JS220LC, JS235 Excavators
• John Deere: 160 LC, 160C LC, 160D LC, 160G LC, 180CW, 180G LC, 190DW, 190GW, 200 LC, 200C LC, 210CW, 210G LC, 220DW, 225C LC RTS, 225C RTS, 225D LC, 245G LC Excavators
• Kato: 820, HD1023 Excavators
• Link-Belt: 160LX, 160X2, 210LX, 225SA, 2700 Quantum, 2800 Quantum Excavators
• Sumitomo: SH150, SH160, SH200, SH200-2, SH200-3, SH200LC, SH200LC-3, SH210-5, SH215U-1, SH215X-1, SH225X-3 Excavators
