Komatsu PC1250-8 Excavator Steel Tracked - 120t for Hire

Our PC1250SP-8R, available in both excavator and face shovel configuration, has a proven reputation across mining, quarrying and very heavy duty construction applications. Key components are designed and manufactured by Komatsu to work together in an integrated package. And it comes standard with our Komtrax Plus remote monitoring and location system, backed by our Australia-wide service and support network.

SPECIFICATIONS

Model Komatsu SAA6D170E-5
Type Water-cooled, 4-cycle, direct injection
Aspiration Turbocharged, aftercooled
Number of Cylinders 6
Bore x Stroke 170 mm x 170 mm
Piston Displacement 23.15 ltr
Horsepower, Gross - SAE J1995 514 kW / 688 HP
Horsepower, Net - ISO 9249 / SAE J1349 502 kW / 672 HP
Rated RPM 1800
Fan drive method Hydraulic

Drives and Brakes

Steering control Two levers with pedals
Drive method Fully hydrostatic
Maximum drawbar pull 686 kN 70000 kgf
Gradeability 70 %
Travel speeds 2.1 / 3.2 km/h
Service brake Hydraulic lock

Swing System

Driven by Hydraulic Motors
Swing reduction Planetary gear
Swing circle lubrication Grease-bathed
Swing lock Oil disc brake
Swing speed 5.8 rpm

Undercarriage

Center frame H-frame leg
Track frame Box-Section
Track type Sealed track
Track adjuster Hydraulic
Number of shoes (each side) 48
Number of carrier rollers (each side) 3
Number of track rollers (each side) 8

Coolant & Lubricant capacity

Fuel tank 1360 ltr
Coolant 142 ltr
Engine 86 ltr
Final drive, each side 21 ltr
Swing drive 2 x 20 ltr
Hydraulic tank 670 ltr
PTO 13.5 ltr
