Specifications
Internal Trailer Size: 3040mm x 1530mm x 425mm
Drawbar: 1800mm, 150mm x 50mm
Hot Dipped Galvanised
Fully Welded Body & Chassis
Removable Front & Rear Drop Down Gates
35 AMP Battery System, Australia Wide Warranty
4.5T 1.2m Hydraulic Cylinder with Hydraulic Power pack
2m 2Ton Under Body Slide Loading Ramps
Flooring: Checker Plate Floor
Tie Down Rails
Axle: Dual Axle, 50mm Round Solid Axle
Brake: 12” Electric Drum On Four Wheels
Springs: 60mm 7 Leaf 7mm Rocker Roller
Wheel Size: 15?
Tyre Size: 195/R15C
Coupling: 50mm 3500kg
Jockey Wheel: 8” Swing up
Tool Box: Aluminium
Light: 12V-24V, LED
Plug: 7 Pin, Flat
Additional Options
600mm / 900mm mesh cage
Ladder Racks
Spare Wheel & Bracket
Additional Tapered Toolbox
Canvas Cover
Ramps Option1: Under Tray Slide Down Galvanised Ramps
Ramps Option2: 2.0t 2000mm X 350mm X 82mm Aluminium ramps
Solar Panel
Tie Down Points
Warranty
5-Year Structural Warranty on all Brand-New Trailers: This warranty excludes coverage for surface rust, mistreatment, damage, or misuse.
1-Year Warranty on Leaf Springs, Lights, Wiring, Jockey Wheel, and All Other Parts.
Warranty Exclusion for Second-hand or Used Trailers or Goods.
