7 Leg Fieldwave Shear-Pin Subsoil Aerator 304P7RPP

Rata Fieldwave subsoilers are designed specifically for use in ground where compaction has occurred. All Rata subsoil aeration equipment with more than 3 legs features a double bar ‘V’ frame construction for a better job and easier pulling.

Why buy a Fieldwave Subsoil Aerator?
V Frame Design for a better job and easier pulling
Ability to aerate almost any type of soil
Auto-reset springs can be retro fitted

The innovative double “V” frame design allows the user to pull more legs with less horse power. Its massive robust construction including 14mm shear bolt leg protection & a heavy duty linkage is designed for the toughest working conditions & high horse power tractors. The 16mm legs have shin guards attached, giving clean results while cutting through the soil.

Features & Benefits

1 V Formation
Rata Fieldwave subsoil aerator legs are in a 'V' formation, this reduces drag between the legs making it easier to pull and uses less fuel. V formation also means the legs leave the ground independently at the headlands which eliminates 'heaving'

2 Heavy Duty Build
Rata Fieldwave subsoil aerators feature a heavy duty build, the 16mm wear protected legs are securely bolted into mounts that are gusseted onto the heavy mainframe for strength.

3 Depth Adjustment
Working depth on the Fieldwave aerator is easily controlled via the rear roller setting and tractor 3 point linkage. The rear roller is secured to the main aerator frame with heavy machine pins.

4 Flange Roller Bearings
The rear roller on the Fieldwave Aerator is securely mounted into a sealed bearing to ensure smooth operation with minimal wear. The roller is also kept clean by a scraper mounted just behind.

5 Modular Foot
An innovative modular leg, foot & point assembly provides maximum flexibility of parts. Cast point features extra wear protection in the form of beveled hard wearing plate.

Specifications
Model (Code): 304P7RPP
Number of Legs: 7
Working Width: 3.50 m
Max Working Depth: 450 mm
Recommended HP: 150

Pricing doesn't include freight, located in Ballarat VIC. Contact us for more information or to arrange an inspection.
