Specifications
ATM: 1800kg
Internal Trailer Size: 2440mm x 1530mm x 425mm
Drawbar: 1500mm, 120mm x 50mm
Hot Dipped Galvanised
Fully Welded Body & Chassis
Removable Front & Rear Drop Down Gates
Deep Cycle Battery System
2.0T 3 stages Hydraulic Cylinder with Hydraulic Power pack
Flooring: Checker Plate Floor
Tie Down Rails
Axle: 50mm Round Solid Axle
Brake: 12” Electric Drum On Two Wheels
Springs: Heavy Duty 60mm wide 8 Leaf 8mm Eye to Eye Offroad Spring
Wheel Size: 15?
Tyre Size: 195 R15C
Coupling: 50mm 3500kg
Jockey Wheel: 8” Swing up
Tool Box: Steel
Light: 12V-24V, LED
Plug: 7 Pin, Flat/ Small Round/ Big Round
Additional Options
600mm / 900mm mesh cage
Ladder Racks
Spare Wheel & Bracket
Canvas Cover
Solar Panel
Side Wall Tie Down Points
Blueslip
On-Site Registration in 10 mins
Warranty
5-Year Structural Warranty on all Brand-New Trailers: This warranty excludes coverage for surface rust, mistreatment, damage, or misuse.
1-Year Warranty on Leaf Springs, Lights, Wiring, Jockey Wheel, and All Other Parts.
Warranty Exclusion for Second-hand or Used Trailers or Goods.
