Specifications
Internal Trailer Size: 2400mm x 1530mm x 300mm
Side: 425mm High, Fully Welded
Drawbar: 1800mm, 150mmx50mm RHS
Removable Front and Rear Drop Down Gates
Welded Ladder Racks Holders
2 Heavy Duty Locking Points On Drawbar
Flooring: Checker Plate Floor
Tie Down Rails All Around
70mm x 50mm SHS Reinforced Under Floor
(From Left To Right& Front To Back)
Fully Step-up Platforms On Both Sides
Axle: Dual Axle, 50mm Round Solid Axle With Parallel Bearings
Brake: 12? Electric Drum Brake On Four Wheels
Springs: 60mm 7 Leaf 7mm Rocker Roller
Wheel Size: 15?
Tyre Size: 195/15
Coupling: 50mm 3500kg Electric
Jockey Wheel: 8” Swing up
Light: Tail Light, LED
Plug: 7 Pin, Flat/ Small Round/ Big Round
Additional Options
600mm / 900mm mesh cage
Ladder Rack
Spare Wheel & Bracket
Drop Down Corner Steadies
Drop Down Ramp
Rectangle Tool Box – 1200mm x 400mm x 350mm
Rectangle Tool Box – 980mm x 320mm x 320mm
Tapered Tool Box – 960mm x 470mm x 290mm
Tapered Tool Box – 590mm x 450mm x 300mm
2.0t 2000mm X 350mm X 82mm Aluminium ramps
Aluminium ramp holders
Side Wall Tie Down Points
On site Registration in 10mins
Blueslip
Warranty
5-Year Structural Warranty on all Brand-New Trailers: This warranty excludes coverage for surface rust, mistreatment, damage, or misuse.
1-Year Warranty on Leaf Springs, Lights, Wiring, Jockey Wheel, and All Other Parts.
Warranty Exclusion for Second-hand or Used Trailers or Goods.
