AGMA A-14 Vertical Machining Centre

A-14

All three axes adopt high precision 45mm roller-rail linear guideways and Ø45mm ball screws. A12/A14’s unique four roller-rail linear guide ways with eight sliders on the Y axis enable the ultimate support for high speed and machining accuracy. With Meehanite cast iron across the mach ine structure, machine column and saddle are carefully designed with dual layers casting for the most rigid structure to absorb cutting vibration.

Standard Accessories
FANUC OiMF 8.4" Controller
Heat Exchanger for Electric Cabinet
Program Execution/End/Abnormal Three Color Indite Light
Quartz Work Lamp
Fluorescent Lamp
RS-232 Interface
Oil Circulating Coolant System for Spindle
Spindle Air Blast
Automatic Lubrication Equipment
Protection Device for Three Axes Slide Ways
Full Splash Guard
Rigid Tapping
Auto Power Off
14.Y-Axis Screw Type Chip Auger (4 pcs)
Tool Box w/Leveling Bolt
Machine and Electric Operation Manual
(380/220V) Transformer (Exclude India, USA and Canada)
CE/CSA Electrical Specification (For European/Canada Only)

Optional Accessories
FANUC 31iMB Controller
Mitsubishi 70/720/730M controller
Direct Driven Spindle 10,000/12,000/15,000RPM (BT-40)
Gear Driven Spindle 6,000rpm (BT-50)
Coolant-Thru Tool Holder
Three Axes Optical Linear Scale
Oil Mist
Oil Mist Collector
Coolant Through Spindle A Type (20 Bars)
Renishaw TS-27R Tool Setup Probe (Tool Setter)
Disc Type Oil Skimmer
CNC Rotary Table
Air Conditioning Equipment for Electric Cabinet
4Th Axis Interface
