The Ace Micromatic Simpleturn 5035 XL is a robust flat bed CNC lathe designed for reliable day-to-day turning in jobbing, general engineering, and light production environments.
Built by one of India’s largest machine tool groups, the 5035 XL focuses on rigidity, simplicity, and ease of operation. It is well suited to workshops looking for a proven CNC lathe without unnecessary complexity.
Key Capabilities
• Swing over bed: 500 mm
• Maximum turning diameter: up to 320 mm
• Maximum turning length: 350 mm from chuck face
• Flat bed construction with hardened and ground guideways
• Direct drive spindle for consistent torque and low maintenance
• 4-station vertical axis turret as standard
Spindle & Performance
• A2-6 spindle nose
• Up to 2000 rpm spindle speed
• 7.5 kW AC induction spindle motor
• Suitable for chuck and bar work (capacity dependent on configuration)
Axes & Motion
• X-axis stroke: 300 mm
• Z-axis stroke: 350 mm
• Hardened and ground dovetail guideways (X)
• Hardened V and flat guideways with steel strips (Z)
Standard Inclusions
• Coolant system
• Automatic slideway lubrication
• Electronic handwheel on control console
• Machine work light
• Protective covers for ball screws and Z-axis
Typical Applications
• General turning and facing
• Shafts, bushes, flanges, and short production runs
• Toolrooms, maintenance workshops, and training environments
The Simpleturn 5035 XL delivers a practical balance of capacity, durability, and value. It is a strong option for workshops wanting dependable CNC turning backed by local Australian support from QMT Machinery.
