The Athena 850 BL offers a powerful 250 kg basket capacity, 7.9m max height, and advanced features like automatic leveling, easy-drive system, and high-speed capabilities for efficient, safe work.
Year: 2016
Working hours: 1660
Non-marking tracks
Condition Notes:
- Machine in excellent condition.
- Full re-spray and safety decals
Technical Specifications
Platform Capacity: 250 kg (2 operators)
Platform Size: 1.50 x 1.20 m
Max Working Height: 7.9 m
Max Height Platform Floor: 5.9 m
Moving Height: 6.0 m (5.0 m)
Powered by: Hatz 1B40
Accelerator: Automatic
Undercarriage: Bi-Levelling
Platform Levelling: Automatic
Longitudinal Levelling Front: ±16°
Longitudinal Levelling Rear: ±20°
Lateral Levelling: ±15°
Power Generator (Option): 220V-1kW
Electric Pump (Option): 220V-2.2kW
Hydraulic Commands: Proportional
Direction-Control System: Yes
Easy-Drive System: Yes
Kit for High Speed: Max 2.40 km/h
Ground Emergency: Yes
Control of Inclination: Automatic
Pro-active Levelling: Yes
Gradeability: 25°
Side Slope: 21°
Length: 1.94 m
Width: 1.30 – 1.50 m
Total Weight: 2190 kg
Compliance: EN 280, ANSI, CSA, ASNZS1418
