Atlas Copco QES-20 – Versatile General-Purpose Generator

Atlas Copco QES-20 – Versatile General-Purpose Generator
The QES range provides a practical and flexible solution for mobile, stationary, prime, or standby power in a wide range of industries.
These units are mounted on a galvanized steel skid with integrated fork pockets for easy handling and installation.

Key Specifications:
• Engine: Kubota V2403-M-E3BG2 Diesel
• Alternator: Atlas Copco ACA180C with Auxiliary Winding
• Power Output: Prime – 20 kVA (16 kW) | Standby – 21 kVA (17 kW)
• Controller: Deep Sea DSE-4620
• Voltage Control: AVR
• Governor: Electronic
• Fuel Tank: 125L (24-hour runtime) with lockable cap
• Fuel Connection: External valve for bulk tank integration
• Frame: 110% bunded base, galvanized steel (painted)
• Noise Level: 67 dBA 7m
• Safety Features: Earth leakage relay, external E-stop, Battery Isolator
• Dimensions: 1540mm x 700mm x 1250mm
• Net Weight: 705kg
