Smooth levelling and good steering sensitivity
Euro emission, green and environmental protection
Compact design and folded jib, easy to transport
300kg/454kg dual capacity for flexible application
Size
Work Height 16.6m
Platform Height 14.6m
Horizontal Outreach 12.7m
A - Stowed Length 9.6m
B - Stowed Width 2.28m
C - Stowed Height 2.52m
D - Platform Length 2.44m
E - Platform Width 0.91m
F - Wheelbase 2.36m
Tread 2.28m
G - Ground Clearance 0.36m
