BusBar Machine Punch, Shear & Bend BM303

Bus Bar Machine
3 in 1 Combination
Suit Switchboard Manufacturers

Function: PLC assist busbar punching, shearing, level bending, vertical bending, twist bending.

Character: 3 unit could work at the same time. Punching unit have 8 punching dies position. Auto-calculate material length before bending process.

Output force:

Punching unit 350 kn

Shearing unit 350 kn

Bending unit 350 kn

Material size: 15*160 mm

With appropriate dies, the punching unit could process round, oblong and square holes or emboss a 60*120mm area on busbar.

This unit adopts turret-type die kit, capable of storing eight punching or embossing dies, the operator could select one punching dies within 10 seconds or completely replace the punching dies within 3 minutes.

The bending unit could process level bending, vertical bending, elbow pipe bending, connecting terminal, Z-shape or twist bending by change the dies.

This unit is designed to be controlled by PLC parts, these parts cooperate with our control program could ensure you have easy operate experience and high accuracy workpiece, and the whole bending unit placed on a independent platform which ensure all three units could work at the same time.
