CATERPILLAR® 260 SKID STEER LOADER

The Cat® 260 Skid Steer Loader, with its vertical lift design, delivers extended reach and lift height for quick and easy truck loading. Its stability and lifting performance provides excellent material handling.

Gross Power - SAE J1995:2014
55 kW

Rated Operating Capacity
1434 kg

Operating Weight
3866 kg

Redesigned Operator Station:
Delivers a larger operating environment and combined with additional seat travel, the 260 provides more space for operators of any size. The optional one-piece, sealed, and pressurized cab offers a clean and quiet workspace with excellent air distribution through optimally placed vents throughout the cab.

Available ventilated and heated high-back air ride seat:
With seat mounted adjustable joystick controls deliver industry-leading operator comfort.

High performance power train:
Provides maximum performance and production capability through the Electronic Torque Management system, optional two speed travel and an electronic hand/foot throttle with decel pedal capability.

Three levels of auxiliary hydraulic performance available, Standard Flow, High Flow, and High Flow XPS:
Standard flow for attachments that require a base level of auxiliary flow and horsepower, High Flow boosts the auxiliary flow for applications that demand additional hydraulic flow for increased attachment performance, and the High Flow XPS hydraulic system provides maximum auxiliary hydraulic performance by delivering additional flow and additional pressure for the most demanding attachments and applications.

Electronically controlled Cat C2.8T engine:
Meets Brazil MAR-1 emission standards, equivalent to U.S. EPA Tier 3 and EU Stage IIIA standards while delivering maximum horsepower across a wide RPM range and providing high torque for increased working performance, no matter the application.

Speed sensitive ride control option
Improves operation on rough terrain, enabling better load retention, increased productivity, and greater operator comfort.

Maximize machine capability and control:
With the Advanced Joysticks and Advanced Touchscreen Monitor. The 20.3 cm (8-inch) Advanced Touchscreen monitor offers cutting-edge functionality and control that includes an integrated radio, Bluetooth® connectivity, and multi-camera (side-view) option, and supports 32 different language choices. The Advanced Joysticks provide unmatched control of machine functions and adjustments within the display without the operator having to remove their hands from the controls. This includes on-joystick navigation of the Advanced Touchscreen Monitor, radio volume up/down/mute, creep activation, creep speed increment/decrement, one-button Smart Attachment control activation, and additional auxiliary control buttons that deliver single button control of complex attachment functions.

Ground-level access
To all daily service and routine maintenance points helps reduce machine downtime for greater productivity.

Broad range of performance matched Cat Attachments
Make the Cat Skid Steer Loader the most versatile machine on the job site.

For more information, please download the brochure.
