Chainless TH205 > Extreme Duty > Round & Square Bale Feeder, Feedout Cart

Feed out literally any round or square bale of any forage type with the Hustler Chainless. Even the tightest hard center bales and frozen bales are no match for Chainless. The unique 3:1 feeding mechanism teases apart the bale making them go further without destroying nutrition which farmers are reporting saving up to 30% in feed costs compared to other bale feeders and processors! It’s self-loading with a patented total control loading system and carries two bales per load.

Pull-type, Self-Loading, Chainless Round & Square Bale Feeder.
The Chainless trailed square and round bale feeders are self-loading, suitable for feeding out any bale, round or square, and it maximises feed use. Designed for medium to large operations. A Chainless feed out cart minimises feed waste by feeding out into narrow windrows to make the feed more accessible to animals and all but eliminate damage from hoof trampling, manure spoilage, and animals laying down on the feed. More efficient use of power, savings on machinery investment and faster bale feeding all add up to impressive fuel economy – made possible by the hydraulic drive system at the heart of every Hustler Chainless trailed bale processor.

Latest Chainless TH205 – Extreme Duty
Extras & upgrades include:

- Larger 400/60/15.5 floatation wheels/tires standard
- New Puckboard floor – almost indestructible with 10 year warranty!
- More powerful bale loading system for heavier bales even 5’ wide x 6’ diameter bales load with ease
- Induction hardened pin and line-bored and press fit hardened steel bush system that don’t flog out. Same system as used in excavator booms which is superior to any bronze bushing system
- Beefed up chassis, platform frame, drawbar and entire Total Control Loadings System
- New 5 position wiper chute extension – ideal for feeding into bunks, troughs or to prevent machine running over feed
- Alloy hydraulic hose grips with markings for easy connection to tractor
- Loading spear position indicator for easy loading
- Quick release wiper for easy maintenance
- Large string box with improved lid design for net and wrap waste
- Bolt on axles for more flexibility and easier maintenance
- Square bale platform extension (Standard in Australia. Optional in other markets)


Specs:
Bale Sizes Round: Up to 5’ x 6’
Bale Sizes Square: All sizes
Bale Weight: Up to 1500kg each
Unit Weight: 1400kg
Hydraulics Required: 2 x double-acting, 2250-3000 psi
Capacity: 2 bales (round or square)
Tynes: 2 x forged high-tensile
Towing Eye: Adjustable height, 45 mm swiveling forged 12t rated
Axles: 6 stud
Wheels: 400/60/15.5 flotation
Ground Clearance: 495mm
Loading: Patented Total Control self-loading system

Options:
> Fenders
> Even Feed Roller
> Extra loading spears
