Cloveragri HEAVY DUTY 2.2m VMZS 220 Mulcher inc spare blades and belts

CLOVERAGRI HEAVY DUTY VMZS220 MULCHER MOWER.

The quality robust construction of the Heavy Duty VMZS220 Mulcher Mower Series makes them stand out from its competitors. Heavy duty special reinforced angular gearbox, heavy duty drive shaft and hammer blades with rear open bonnet are just some of the outstanding features.

The heavy duty mulcher series is well suited to farm tractors from 70hp upwards.

A mulcher mower advantage over a slasher is :

1. Maneuverability
2. Superior finish ( no windrows )
3. Better rejuvenation of the pasture.

The Modern design and technology of a mulcher is fast replacing the old traditional Slasher. The safety is also improved with a mulcher as all pasture is cut inside the main body and only discharged as finer less dangerous clippings.

The heavy duty mulcher series are driven using a supplied P.T.O shaft via the tractors rear mounted Power Take Off ( PTO ). Being Hydrualic offset to the right hand side of the tractor allows the mulcher / mower to easily cut close to fence lines or under trees. The VMZS rang includes an extended head stock to further offset the mower to the left hand side of the tractor.

Due to the open rear bonnet, maintenance work or changing hammer blades is easily accessible. Please be informed that the bonnet is recommended to be closed while operating.

The specially hardened, 1.2 kg hammer blades, which are arranged on a double spiral drive shaft, shred clippings to a minimum size. Even very high grass, bushy or straw-like clippings are no problem for this mulcher mower!

The mulcher mower additionally has a trailing roller and a freewheel gearbox. The cutting height can be set with the adjustable roller and side mounted skids. The suspended, galvanized safety covers at the front of the mower unit prevents stones or other foreign objects escaping.

Hydraulic side shift comes standard on the VMZ model. By using the hydraulic side shift function the mulcher can be moved to both left and right. For this function you need a hydraulic control circuit on your tractor, as the mower unit has a double-action hydraulic cylinder for this purpose.


VMZS220 Specifications:

Length: 2350 mm

Width: 1050 mm

Mowing length: 2200 mm

Weight: 769kg

P.T.O shaft Included

Rpm: 540

drive shaft Ø: 168 mm / 10mm thickness

trailing roller Ø: 150 mm

Hammer Blades : 24 pieces

Drive: 5 piece drive belt

Dimensions of packaging: 2700x1100x950 mm (L x W x H)

Mounting: three point hitch from Cat. 2

Tractor: min. 70HP

Deck thickness : 5mm Doubled Skinned

Side Wall thickness : 10mm

Rakes : 16 pieces

Skid thickness : 8mm


Please Note:

The mower unit is delivered in a steel crate. The gearbox and drive shaft is dry and must be filled with oil
(80W90 GEARBOX OIL ) PTO shaft and other grease nipples require greasing prior to use.

Cloveragri only supply's Quality Implements with the best Welding, Hydraulics, Paint and Design giving 100% product satisfaction. Please don't get caught out with inferior quality that may cost you double in the long run.
