Feeds out literally every supplementary type of feed, including whole round and square bale of all types, shapes and sizes as well as loose feed such as fine chop grass silage, corn/maize silage, root crops, vegetables, by-products and much more.
Introducing the all-new Combi RX² multi-feeder range. With unique features delivering unprecedented feeding versatility, standing as the lowest maintenance wagon on the market, offering unrivaled maneuverability and enhanced feed control. Built upon the success of its predecessor, the Combi RX² incorporates valuable user feedback for an even better feeding out experience.
With more than a decade of extensive product development and testing, working on large-scale farms and ranches around the world, the Combi RX² range is ready for whatever you throw its way.
Round Bales (single layer): 3-8
Medium Square Bales: 8-10
Large Square Bales (8ft long): 8-10
Loose Silage (Load Level): 17 m³ | 600 ft³
Loose Silage (Heaped Load): 20.5 m³ | 724 ft³
Maximum Load: 14,000 kg | 30,865 lb
Overall Width: 3015 mm | 118.7 in
Overall Length: 7898 mm | 311 in
Overall Height/Loading Height: 2496 mm | 98.3 in
Tare weight: 4900 kg | 10803 lb
Standard Tyres: 500/50 x 22.5 Flotation Grip Tread
Axle: Tandem Walking Beam
Brakes: Optional 2 or 4 Wheel Braking
Weigh Scales: Optional Feedlink weighing and feed management system
Floors (Bed Floor / Cross Floor): 15 mm (0.6 in) HD Puck Board
Chains (Bed / X floor / Elevator): Chainless / Twin 12,000 lb Roller Chains / Twin 12,000 lb Roller Chains
Feed bars (Bed / X Floor / Elevator): Twin Hydraulic Rams / 65 x 35 RHS / 40 x 40 RHS
Joystick: In-cab Electric Control w/ Bales and Silage Mode
Hydraulics Required: 2 x double-acting
Hydraulic Flow: 50-70 L/min (80 L/min maximum) | 13.2-18.5 gal/min (21.1 gal/min maximum)
Hydraulic Pressure: 2050-2500 psi | 140-170 bar
Elevator: 1645 mm | 64.7 in wide chain/slat
Jack: 80 mm | 3.1 in 2-speed screw, with quick adjustment. Designed strong enough for use as quick hitch stand
Towing Eye: 50 mm | 2 in swiveling forged eye
