The PC3-240 Converter is part of the Premium Rotary Converter Series. It features microprocessor controlled thyristor switching and 9 stage automatic voltage control with hard start capability.
It operates on 240V single phase input and delivers 400V three phase output with ±5% phase to phase voltage tolerance.
Specifications
• Model: PC3-240
• Output Power: 3kW
• Output Rating: 4HP
• Three Phase Motor Starting: 6.5 Amps
• Maximum Input Current 240V: 16 Amps
• 15A 240V Plug Top Standard
• Enclosure Dimensions: 60 x 60 x 30 cm
• Internal Pilot Motor
• 2 Year Manufacturer Warranty
Standard Features
• Premium rotary converter design
• Microprocessor controlled capacitor boosted hard start
• Automatic 8 step electronic capacitor switching with 5% voltage control
• Digital display for load indication and fault codes
• D Curve circuit breaker and thermal overload protection
• Suitable for CNC controlled machinery, 3 phase VSDs, inverter welders and plasma cutters
