EXIMUS Precision Lathe LA660x3000

***Just Arrived & In Stock**
EXIMUS LA 660mm SWING CENTRE LATHE 3000mm BETWEEN CENTRES - MANUFACTURED IN TAIWAN

LA Machinery is one of Taiwan's leading manufactures of conventional and CNC lathes. Whitelaw Engineering machinery have supplied hundreds of these high quality centre lathes to tool rooms, schools, training colleges, automotive workshops and engineering companies throughout the Oceania region.

Don't take the risk by buying inferior quality products for your business, visit our or call for details on the complete range of Eximus machine tools manufactured in Taiwan.

Eximus Taiwan offer one of the most comprehensive range of Heavy Duty Turning Machines for virtually any and all applications, from Oil Field, to Heavy Industry, Energy, Steel Mills, and Jobbing Shops. With a range of spindle bores from 104mm-535mm through to an incredible 3600mm swing over the bed, and up to 12000mm between centres. Now with a large number of reference sites here in Australia Whitelaw Engineering Machinery can arrange a demonstration at your convenience. Call Ryan for more details.

MODEL LA6603000 SERIES BIG BORE CENTRE LATHE

KEY FEATURES:

Swing over bed: …670mm
Swing over cross slide: …460mm
Swing over gap: …890mm
Width of bed: …460mm
Distance between centres: …30000mm
Spindle bore: …Ø 104mm
Spindle speeds (Range): …Varies with bore size
Spindle taper: …MT#5
Main spindle motor: …20HP
Approx weight: ... 3800g

STANDARD EQUIPMENT:

Auto lubrication system
Star delta soft start
Full length splash guard
Rapid traverse to long and cross feed
Coolant System
Rear chuck mount
Work light

***INCLUDED UPGRADE PACKAGE***:
--Quick change tool post (Taiwan)
--400mm/16' 3-JAW CHUCK CHANDOX (Taiwan)
--450mm/18' 4 JAW CHUCK CHANDOX (Taiwan)
--2 Axis digital readout
--Travelling and fixed steady rests
--OH & S Guarding

OPTIONAL EQUIPMENT:
Taper turning attachment
Hydraulic copying attachment
Boring attachment
