Edge sander VOLPATO New

The sanding machinery and finishing machinery catalogue.
With a team of highly trained professionals and long-term experience in the industry, VOLPATO deals with the production of sanding and finishing machines for wood and also for plastic and metal materials, that can offer customers excellent quality standards. In fact, trusting the company, means always receiving the best technical and commercial support and having the opportunity to obtain high performance machinery that allows for the creation of a finished product of the highest standard.

Optimize expensive labour costs - Save time and money by eliminating laborious edge sanding tasks with VOLPATO edge sanders. Call us anytime for a quotation on the model of your choice.

Combined sander with multiple processes, oscillating abrasive belt and adjustable abrasive wheel unit
in line with the pad. Mechanical independent oscillation with an excursion of 20mm.
The group complete sanding machine is electrically adjusted in height to exploit the entire sanding belt.
Series complete with abrasive rollers with diameters of 25/30/35/40/45/50 mm. The machine is equipped
with drive advancement with lower belt and with upper pressure rollers. The driving pulley is rubberized, obtained
helically and perfectly balanced. Solid side worktop tiltable from 0 - 45 ° with horizontal displacement and
worktop on the pad side fixed at 90 °. Micrometric adjustment of the guide inlet on the buffer side to achieve
the desired removal depth. Connection to the centralized suction system with a diameter of 150 mm and an
additional one with a diameter of 100 mm it allows an effective evacuation of dust on each working point.
The machine is supplied complete with CE standards, suction hoods, service keys and instruction booklet.
• Double side sanding machine for solid and veneered edges and one abrasive wheel in line with the pad.
• Mechanical oscillation.
• Variable speed of the abrasive belt, ideal for sanding paint or sensitive products.
• The complete sanding unit is vertically motorised to allow full use of the belt.
• Complete set of abrasive rollers Ø 25/30/35/40/45/50 mm.
• The machine is equipped with a belt feeder with pressure rollers on top and variable speed.
• Rubber driving pulley, helically rifled and perfectly balanced.
• Working table on solid side tilting from 0 to -45° and working table on veneer side fix to 90°.
• Entrance fence bracket, adjustable micrometrically to determine the depth of material to remove.
The machine needs just one connection of Ø 150mm and a supplementary connection of 100 mm, to the suction system and guarantee an efficient evacuation of the dust on all work points.
• Complete with dust hoods, spanner, instructions book.
