- Can deliver Australia-wide.
- Available in Green or Red.
Key Performance Highlights
• Max Working Height: 11.8 m, Max Working Height: 9.8 m – Tackle high-reach tasks with confidence.
• Platform Size: Spacious 2.3 × 1.15 m with a 0.9 m extension deck for extra reach.
• Lift Capacity: 320 kg (113 kg on extension) – carry crew & tools effortlessly.
• Compact & Agile: 0/2.8m inside/outside turning radius, front-wheel drive, ideal for tight spaces.
• Gradeability: 25% – handles slopes with ease.
Premium Build & Safety
• High-strength manganese steel struts (Q500D) – rugged, cold-weather-ready (-30°C).
• DTC Control System – trusted by top brands like Genie & JLG for safety & reliability.
• SANT Hydraulic Valves – smooth, stable lifting with automatic flow adjustment.
• Non-marking KOBURA tires – protect indoor floors while gripping firmly.
• Full safety suite – tilt protection, overload protection, emergency descent, automatic braking & pothole protection.
Power & Efficiency
• XUPAI Maintenance-Free Batteries (4×6 V/200 Ah) – strong, long-lasting, eco-friendly.
• SLB High-Efficiency Charger – full charge in just 5.5 hours, auto-shutoff to protect battery life.
• 4.5 kW Pump Motor – fast, smooth operation with 3–5 m/min lift speed.
Built to Last
• Electrophoresis + Plastic Spray Coating – superior corrosion & wear resistance.
• QPQ Pin Treatment – prevents rust, extends service life.
• All-weather durability – engineered for long-term heavy use.
Certification
• AS/NZS 1418.10 – 2025
• EN 280-1 - 2022
