The FMWORLD WD704F canopy tractor, featuring a 12F+12R shuttle shift, is engineered to deliver high performance and versatility — ideal for soil preparation, loading, mowing, and towing.
3-year full-machine warranty | Spare parts warehouse in 9 Noblevale Way, Swanbank, QLD 4306
Structure & Drive:
• Drive Type: 4WD (Four-wheel drive)
• Chassis: Swing-type drawbar + vertically adjustable drawbar
• Safety Structure: ROPS (Roll-Over Protective Structure)
• Front Mudguards: Equipped
• Warning Lights: Equipped
• Wheelbase: 2137 mm
Engine:
• Rated PowerSpeed: 70HP 2400 rpm
• Engine Type: 4-cylinder, vertical, water-cooled, 4-stroke diesel engine
• Fuel System: Euro-standard emissions compliant
• Fuel Tank Capacity: 115L
• Battery Voltage: 12V
• Air Cleaner: Dry-type
Transmission:
• Gearbox: 12 forward + 12 reverse shuttle shift (with creeper gear)
• Clutch: Dual-stage clutch
• Brake System: Mechanical Disc
• Differential Lock: Pin Type, Mechanical
PTO (Power Take-Off):
• Shaft Diameter: 35 mm
• PTO Speed: 540 / 1000 rpm ?Optional configurations include 540/760 or 760/1000 rpm PTO speeds.
• PTO Valve: Multi-way hydraulic valve with safety lock
• Rotation: Clockwise (viewed from rear)
Hydraulics:
• 3-point Hitch: Category II&I
• Rear Hydraulic Outputs: 2 sets
• Lifting Force: ?1260 kg
• Hydraulic Control: Position + floating control
• Valve System: Multi-way valve with self-locking mechanism
• Loader: Standard front-end loader with 4-in-1 bucket
Tires & Dimensions:
• Agricultural Radial Tires:
• Front: 280/85R24?Other size optional)
• Rear: 420/85R30 (Other size optional)
• Ground Clearance: 470 mm (With a ground clearance of 470 mm, the machine can easily traverse paddy fields and muddy areas.)
• Canopy Dimensions (L × W × H): 3820 × 1850 × 2800 mm
• Minimum Operating Weight: 2760 kg with canopy(2940 kg with Cabin)
Operator Area & Comfort:
• Canopy: Reinforced sunshade (optional A/C cabin)
• Platform: Wide, anti-slip operator platform
• Seat & Steering: Adjustable seat and tilt steering wheel
• Instrument Panel: LED instrument cluster
Price: $30,060.20 (ex-GST)
In stock at Brisbane Warehouse | Test drive available by appointment.
Bulk orders and dealer inquiries welcome!
Interested? Contact us today
We’re happy to answer your questions, send more photos/videos, or arrange an inspection.
