GANNOMAT Express Drilling & Hinge insertion

MADE IN AUSTRIA
CNC bore and hinge insertion machine with magazine feeding for the automatic processing of hinges and hinge mounting plates. Robustness, durability and ease of use distinguish our automatic CNC controlled drilling and insertion machines.
Short introduction:
• CNC controlled hinge boring and inserter for high capacity
• Flexibility through the CNC control
• Massive and robust drilling units
• Inserting die made of steel for a long life time use
• Solid wood drilling with standard 1,5 kW motor
• Safety-control with metal-detector (option)
Through replaceable drill heads Gannomat drilling and insertion machines can process several hardware and hinge manufacturers.

Drilling pattern according hardware manufacturer (e.g. Blum, Grass, Häfele, Hettich, Salice, Würth, ...).
CNC controlled hardware drill and insertion machine with magazine feeding for hinges and mounting plates - GANNOMAT Express CNC - Features and Benefits A large number of various RTA and KD fittings can be processed, e.g. like Häfele Rafix.

The GANNOMAT Software has been developed and programmed by our own software department at our factory to guarantee simpliest programming with great ease to use and with the result that the Express CNC is also suitable for operators with little computer experience.

Dual working zones for high output production (Single working field of 2500mm or dual working fields of 1250mm)
Massive and robust drilling unit ensures reliability and longevity of the machine
Capable of drilling into solid wood cabinet doors with powerful 1.5 kW (2 HP) drilling motor
Drilling & inserting station travels in length direction on profile bearing guides with drive through servo motor and tooth-rod system
