GO Fuel Trailer Self Bunded Dual Axle 500L

FUEL TRAILER 500L Self Bunded Dual Axle SBSD500

Overview
The GO Industrial SBSD500 Self Bunded Fuel Trailer is designed specifically for the transport of flammable liquids such as Petrol, Kerosene, JET A1 and AVGAS. Being under 500L this trailer can be driven on road without the need for a dangerous goods licence.

The SBSD500 Self Bunded Fuel Trailer is supplied with a longer chassis to provide a safe separation distance for the 12V power and control system needed for flammable liquids dispensing.

Specifications

Self Bunded - True self bunded, tank in tank design.
Tare Weight - 790kg
Fully Approved - designed and approved to meet the requirements of AS1692, AS1940 and Australian Dangerous Goods Transport Regulations.
Tried and Proven - we have been manufacturing and supplying this design trailer for more than 10 years now. It is a tried and proven option for the transport of flammable liquids including Petrol, Kerosene, AVGAS and JET A1
Removable Inner Tank - The primary tank module can be removed for maintenance. For AVGAS and JET A1 applications we provide a 304 SS Primary Tank with 304 SS Wetted Parts.
Separate Tank and Trailer Chassis - the secret of our success, our tank body is protected from the twisting and rigours associated with road towing and use. Our chassis is designed to take the mechanical stresses and strains of in field use, protecting the tank body from the risks of cracking over time.
Dispensing Options - common dispensing options include High Flow Manual Pump or Flammable Rated 12V Dispensing System with Battery Pack
Baffled - our self bunded tank module is fully baffled ensuing stability when towing loaded.
Roof Mounting Options - The trailer roof allows for mounting of a Spill Kit or other site support equipment
110% Bunded - the tank module is a true 110% self bunded tank with tank design. The inner tank can be removed for maintenance over time.
Running Gear - 185/14 Light Truck Tyres | 14" White or Black Sunraysia Style Rims | 5 Stud Pattern | Spare Tyre with Spare Tyre mounting assembly.
Fully Lockable Tank - the self bunded tank module can be locked, discouraging access and ensuing theft of fuel from the trailer
Contents Management - Calibrated aluminium dipstick with optional mechanical dial type level indicator
Spare Ports - Numerous spare ports for connection of instrumentation,
Fill Tube - Anti static fill tube
Bunded Fill Point - Fully bunded fill point to catch any drips and drops during refilling operations
Removable Hatch - Removable hatch for access to the inside of the primary tank
Mechanical Override Braking - no need for any in vehicle braking controller / electrical braking system. The GO SBSD500 500L Self Bunded Fuel Trailer can be towed by any suitably rated vehicle.
Chassis - Lightweight yet strong aluminium, dual axle chassis with Roller / Rocker suspension system
Lighting - LED Multi-Volt (12-24V ADR Approved) Trailer Lighting
Trailer Hitch Options - choice of Hitch assemblies including 50mm Ball, Tregg, Pintle Ring
Jockey Wheel - Heavy Duty Swing-away Jockey Wheel
