Electric for variable feed 400 V/50 Hz,2.2 KW
Edge Control 19 -with 18.5" colour touchscreen 16:9. Powerful controls and simplest machine operation. Efficient machine set up and re-setting.
Motoric Infeed Fence - for the exact feeding of the workpiece to the pre-milling unit, automatically adjustable through the control panel for the regulation of the chip dropping during milling.
Edge Feeder 1903 SYNCHRO - automatic transport of roll and strip products Max. load capacity: 40 mm
Glue Application System Glu Jet GJ301 Automatic (2.3kW,50 Hz) Automatic adjustment of gluing height (tracing nozzle)
Processing EVA and PUR adhesives. Glu Jet hybrid technology. Processing of neutral and coloured adhesives. Heat up time 3 minutes.
Pressure Section 1913 MOT - first roller driven,2 support pressure rollers. PLC controlled adjustment of edge thickness via NC servo-drive.
End Trimming Unit 1918 (60 mm) Pneumatic - (2 X 0.45 kW,12000 min-1)
Multifunctional Trimming Unit 1827 MOT 4 - cutting of the top and bottom longitudinal edge.
Form Trimming Unit 1833 MOT 4 - (2 X 0.65 kW,200 Hz,12000 min-1)
1929 MOT 4 Scraper Unit - includes high gloss package
Surface Glue Scraper 1964 - Scraping out superfluous glue for a clean glue line
Buffing Unit - (2 X 0.12 kW,50 Hz,1,400 min -1)
