IMPERIAL MACHINERY 15KW SCREW COMPRESSOR WITH BUILT IN DRYER

Efficient. Reliable. Built for Daily Production.

The Imperial Machinery 15 kW Rotary Screw Compressor delivers dependable, high-efficiency compressed air for modern woodworking and manufacturing environments. Designed for continuous operation, this 10 bar industrial system provides stable airflow, low noise performance, and energy-efficient output — ensuring your machinery runs smoothly throughout the day.

With a direct-drive transmission, IP54 protected motor, and air-cooled design, the compressor offers reduced maintenance, long service life, and consistent pressure, making it the ideal solution for small to medium production workshops.

Compact yet powerful, it supplies clean, reliable air for CNC routers, nesting machines, edge banders, and full production lines.

Key Features

• 10 bar working pressure for industrial applications
• Efficient 15 kW motor for daily factory use
• Stable 1.8 m³/min air delivery
• Direct drive system for maximum energy efficiency
• Low noise operation (? 78 dB)
• Air-cooled design for temperature stability
• IP54/F motor protection for workshop environments
• Automatic start system for easy operation
• Low oil carryover (? 3 ppm) for clean air output
• Compact footprint for easy installation

Ideal For

• CNC nesting machines
• Cabinet & joinery workshops
• Edge banders and drills
• Small–medium factories
• 8–12 hour daily production

Technical Specifications

• Working Pressure: 10 Bar (1.0 MPa)
• Air Volume: 1.8 m³/min
• Motor Power: 15 kW
• Motor Speed: 2980 r/min
• Voltage/Frequency: 415V / 50Hz
• Drive Mode: Direct drive
• Cooling: Air cooling
• Protection Class: IP54/F
• Noise Level: ? 78 ±2 dB
• Outlet Size: G3/4”
• Dimensions (L×W×H): 1050 × 750 × 1030 mm
