IMPERIAL MACHINERY 22kw SCREW COMPRESSOR WITH BUILT IN DRYER

High Capacity Air. Continuous Duty. Built for Heavy Production.

The Imperial Machinery 22 kW Rotary Screw Compressor is engineered to deliver powerful, stable compressed air for high-demand manufacturing environments. Designed for continuous industrial use, this 10 bar system provides consistent airflow, low noise operation, and energy-efficient performance — making it ideal for CNC nesting lines, edge banders, drilling stations, and full factory automation.

Featuring a direct-drive transmission, heavy-duty motor, and air-cooled design, the compressor ensures maximum reliability, reduced maintenance, and long service life, keeping your production running smoothly with minimal downtime.

Built for workshops that require higher air volume and stronger performance, this unit is perfectly suited for medium to large factories operating multiple machines simultaneously.

Key Features

• 10 bar working pressure for industrial applications
• High-output 22 kW motor for demanding workloads
• 1.8 m³/min air delivery for stable continuous supply
• Direct drive system for improved efficiency and reduced losses
• Low noise operation (? 78 dB)
• Air-cooled system for consistent temperature control
• IP54/F motor protection for harsh factory environments
• Automatic start system for reliable daily operation
• Low oil carryover (? 3 ppm) for clean compressed air
• Compact, space-efficient design for easy installation

Ideal For

• CNC nesting machines
• Cabinet & furniture production lines
• Edge banders and drills
• Automated factories
• Multi-machine workshops
• Continuous 8–24 hour operations

Technical Specifications

• Working Pressure: 10 Bar (1.0 MPa)
• Air Volume: 1.8 m³/min
• Motor Power: 22 kW
• Motor Speed: 2980 r/min
• Voltage/Frequency: 415V / 50Hz
• Drive Mode: Direct drive
• Cooling: Air cooling
• Protection Class: IP54/F
• Noise Level: ? 78 ±2 dB
• Outlet Size: G3/4”
• Dimensions (L×W×H): 1050 × 750 × 1030 mm
