IMPERIAL MACHINERY IM-BS500 AUTOMATIC BEAM SAW

Imperial Machinery IM-BS500
Fully Automatic Industrial Beam Saw
High-Speed Cutting. Absolute Precision. Built for Mass Production.

The IM-BS500 is a fully automatic industrial beam saw engineered for high-volume panel processing in modern cabinet, wardrobe, and furniture manufacturing environments. Designed for speed, stability, and accuracy, this heavy-duty system delivers clean, repeatable cuts while maximising throughput and reducing labour dependency.

Built with a reinforced machine frame, servo-controlled positioning, and intelligent CNC control software, the IM-BS500 ensures smooth material handling, precise panel sizing, and consistent cutting quality across every cycle. It is the ideal cutting solution for factories requiring reliable, continuous production performance.

Key Features

• CNC intelligent operating interface
• Servo mechanical gripper feeding system
• Heavy-duty saw car structure
• Precision main + scoring saw blades
• Industrial electrical control system
• Air flotation feeding platform
• Automatic saw carriage device
• Smart side alignment system
• Cutting optimization software
• High-speed return & positioning
• Heavy-duty industrial frame construction
• Large cutting capacity for full sheet processing
Technical Specifications

• Main saw power: 16.5 kW
• Scoring saw motor: 2.2 kW
• Maximum cutting length: 3800 mm
• Maximum cutting width: 3800 mm
• Maximum cutting thickness: 100 mm
• Cutting accuracy: ±0.1 mm
• Servo positioning accuracy: 0.02 mm
• Main blade speed: 4800 r/min
• Cutting speed: 0–100 m/min
• Return speed: 120 m/min
• Total installed power: 26.5 kW
• Air pressure: 0.6–0.8 MPa
• Machine size: 6300 × 7500 × 1900 mm


Ideal For

• Cabinet factories
• Kitchen & wardrobe manufacturers
• Panel furniture production
• High-output cutting lines
• Industrial woodworking plants
