IMPERIAL MACHINERY SCREW COMPRESSOR WITH BUILT IN DRYER

Imperial Machinery Industrial Screw Compressor – 10 Bar
Reliable Power. Continuous Air. Built for Production.

The Imperial Machinery Screw Compressor is engineered to deliver stable, high-efficiency compressed air for demanding industrial environments. Designed for continuous-duty operation, this 10 bar rotary screw system provides consistent pressure, low noise output, and reliable performance — making it ideal for CNC machinery, nesting lines, edge banders, and full factory automation.

Built with a direct-drive design and heavy-duty components, the compressor ensures maximum energy efficiency, reduced maintenance, and long service life, keeping your production running without interruption.

Key Features

• 10 bar working pressure for high-demand applications
• High-efficiency rotary screw air end
• Direct drive system for reduced power loss
• Low noise operation (? 78 dB)
• Air-cooled design for stable temperature control
• IP54/F motor protection for industrial environments
• Automatic start system for reliable daily operation
• Compact footprint for easy workshop integration
• Clean air output with ? 3 ppm oil carryover


Built For

• CNC nesting machines
• Cabinet & furniture factories
• Edge banders & drilling lines
• Automated production systems
• Continuous workshop use


Performance Highlights

• Exhaust Pressure: 10 Bar (1.0 MPa)
• Air Volume: 1.8 m³/min
• Motor Power: 7.5 kW
• Motor Speed: 2980 r/min
• Voltage/Frequency: 380V / 50Hz
• Cooling: Air cooling
• Protection Class: IP54/F
• Drive Mode: Direct drive
• Dimensions (L×W×H): 1050 × 750 × 1030 mm
