660mm swing over bed
460mm swing over cross slide
845mm in gap diameter
330mm centre height
3060mm between centres
400mm bed width
105mm spindle bore
D1-11 spindle nose
15-1200 rpm (12 speed)
75mm tailstock quill diameter
mm tailstock quill travel
MT5 tailstock taper
2 Speed Tailstock
15HP main motor
Mitutoyo 2 axis DRO
Follow rest
1 x Steady Rest (bearing shaft, 3"-8")
12" 3 jaw self centering chuck
18" 4 jaw independent chuck
Rear splash guard
Lead screw protector
Headstock chuck guard with micro switch
Halogen lamp
Longitudinal rapid traverse
Electrical panel and switch with CE approved
Machine size: 4578 x 1280 x 1355mm (LxWxH)
Net machine weight: 3080kg
Gross Machine weight: 3390kg
Available Eagle Farm Brisbane
Buyer to arrange removal and transport
