Ipetronik SIM-STG 519-001-2200 | Strain Gauge 8-Input DAQ Module | CAN Output

Ipetronik SIM-STG – 8-Input Multi-Mode Analog Data Acquisition Module with CAN Output.

This unit is designed for advanced R&D and automotive testing environments, offering versatile functionality and robust build quality. Each of the eight input channels can be individually configured for strain gauges, ICP/IEPE sensors, or voltage signals, making this module suitable for complex and mixed-sensor applications.

Key Features:

8 individually configurable analog inputs

Supported modes: STG, SENS, IEPE

Dual per-channel excitation (±15 V, 45 mA max)

Internal selectable bridge completion resistors

Hardware anti-aliasing and DSP digital filters

Control features: offset adjustment, shunt check, target adjust

Outputs: 2 x CAN

Power supply: 9–36 VDC

Full galvanic isolation (inputs, CAN, housing, power)

Typical Applications:

Automotive test benches

NVH and durability testing

R&D laboratories and mixed-signal environments

Additional Information:


Condition: Good used

Inspection available upon request prior to purchase

Photos form part of the description - sold as is.

Pickup option available or Freight may be arranged at buyer’s cost (please enquire before purchase)
