JACON CONCRETE / SHOTCRETE TRAILER PUMP

Concrete/Shotcrete Pump Specifications:

• Jacon S63 Concrete Pump
• 150mm hardchromed concrete cylinders with 910mm stroke
• 6” x 5” Swinger tube model. with 5” Outlet.
• New JCB 4 Cylinder Diesel Engine 63Kw.
• New Hydraulic Pump and Hydraulic Hoses
• New Electrical Wiring
• Rated Output 0 to 30m3 per hour – Actual approx. maximum 25m3 per hour.
o NB: Performance may vary depending on mix design and pipeline set up.
• Pumping Pressure maximum 47 Bar
• Nominal Vertical reach 50m - Nominal Horizontal reach 150m
• Pumps up to 20mm Aggregates
• Dual circuit hydraulic system for smooth positive swinger tube action.
• Fully automatic stroke adjustment.
• 4 Channel Remote Control Off/On – For/Rev – Rev up – Rev Down

Trailer Specifications:

• Brand new build
• 3T Axle with 12” Electric drum brakes
• 2.5T x 10 leaf off road springs with dampener
• Off Road hanger Kit
• 16” 6 stud 245/75R16 Light Truck wheels
• 3.6T rated jack stand
• Hydraulic jack legs at rear

Dimensions:

• Length: 4.4m
• Width: 1.9m
• Height: 1.8m
• Weight: 2,250Kgs
