KATO HD30V5 EXCAVATOR

KATO HD30V5 Mini Excavator
Powerful. Strong. Reliable. Built for Performance.
Unleash the performance of the HD30V5, KATO’s premium ultra-slewing mini excavator engineered to handle tough Australian job sites with ease. Compact in form but robust in performance, the HD30V5 is the perfect solution for operators demanding reliability, versatility, and operator comfort in a 3-ton class machine.

Superior Power & Efficiency
High Torque Performance: Equipped with a Yanmar 3TNV88F engine delivering 17.2 kW at 2,200 rpm and 83.9 Nm of torque, the HD30V5 ensures dependable power when you need it most.

Outstanding Digging Force: Achieve exceptional productivity with a bucket digging force of 29.1kN and arm digging force of 18.1kN.

Selectable Operation Modes: Maximise fuel efficiency with ECO mode or switch to Vmax mode for top-speed digging and loading.

Engineered for Workability
Advanced Low Center of Gravity Design: Provides enhanced stability (5% more than previous models) and smoother operation in tight or uneven terrain.

Traveling Auto-Shift Mode: Automatically adjusts travel speeds based on load, improving control and reducing operator fatigue.

Skimming Excellence: The shorter gap between bucket and dozer blade allows easy ground skimming — ideal for finishing tasks.

Built for Safety
ROPS 4-Post Canopy: Comes standard for enhanced rollover protection and operator safety.

Emergency Engine Stop Switch: Accessible from outside the cabin, offering extra protection in emergencies.

Dual Parking Brake System: Automatic braking on both slewing and travel systems to prevent unintentional movement.

Durability You Can Count On
Reinforced Dozer Blade & Boom Cover: Built with a square-tube arm and V-shaped dual-layer boom cylinder cover to withstand rugged conditions.

Tough Track Rubber Shoes: High-durability tracks with anti-corrosion steel cords and a spiral structure for extended life.

Steel Pressed Covers: Durable and easy to repair, perfect for demanding job environments.

Comfort-Focused Operator Station
Ergonomic Layout: Wide and comfortable with optimised lever lengths and minimal vibration for reduced fatigue.

Modern Display Panel: Always-lit LED screen with engine error codes to simplify maintenance.

Convenience Features: Includes 12V power supply, cup holder, seat suspension, and improved access via a lowered step.

Low-Cost Maintenance
Tool-Free Access: Side and rear engine panels open easily for quick checks.

Heavy-Duty Filters: Includes double-element air cleaner, large fuel filter, and electric-sensor-equipped water separator.

Specifications at a Glance
Feature Value
Operating Weight 3,095 kg
Bucket Capacity 0.04 – 0.10 m³ (Std. 0.09)
Overall Width 1,550 mm
Travel Speed 2.7 / 4.7 km/h
Ground Pressure 28 kPa
Hydraulic System Pressure 24.5 MPa
The HD30V5 combines Japanese engineering precision with site-ready durability, offering unmatched value in the mini excavator class. Whether you’re working in urban construction, landscaping, trenching, or general hire, the HD30V5 delivers reliable power and smart features to keep your job running smoothly.

???? Contact us today to get a quote. Experience the KATO difference.
