Ganterud L5 Pro – 5-Tonne Radio-Controlled Load Leveller

The Ganterud L5 Pro is a compact, high-precision, radio-controlled load leveller designed for accurate and safe lifting of uneven or awkward loads up to 5 tonnes. As the lightest and most versatile model in the Ganterud Pro range, it is ideal for smaller to medium lifting operations involving prefabricated concrete elements, steel components, machinery parts and other irregular loads.

Equipped with automatic levelling, snatch block rotation, and remote chain release, the L5 Pro allows operators to safely level, rotate and position loads with push-button control. Its adjustable reversible chain system provides flexible levelling reach, while the rugged IP65-rated construction ensures reliable operation in harsh environments from –20°C to +40°C.

The L5 Pro reduces crane time, increases productivity, and significantly improves safety on site — making it a powerful solution for builders, precast manufacturers, riggers and industrial lifting teams.

Key Features

5-tonne lifting capacity for uneven, awkward or imbalanced loads.
Automatic levelling locates the centre of gravity for safe, accurate alignment.
Snatch block function for controlled rotation of heavy or irregular objects.
Remote-controlled chain release keeps operators safely out of danger zones.
Reversible chain system – up to 1.5 m per hook (3 m total).
Reliable in extreme temperatures from –20°C to +40°C.
IP65-rated electrics with welded casing for durability and cleanliness.
IP67 remote control with 7 function keys and 100-metre range.
CE-certified for compliance and safety.

Technical Specifications

Lifting Capacity: 5 tonnes
Load Imbalance: 750 kg
Levelling Length: 1.5 m
Chain Angle: Up to 60°
Chain Size: 10 × 30.5 mm
Total Chain Length: 3 m
Weight: 126 kg
Dimensions (H × W × D): 638 × 503 × 495 mm
Radio Range: 100 m
Motor: 24 VDC
Power (rest/continuous/peak): 50 mA / 24 A / 30 A
Remote: 7-key IP67 unit (3 × AAA batteries)
Operating Temp: –20°C to +40°C
Storage Temp: –20°C to +45°C
Humidity (storage): 0–90%
Unit IP Rating: IP65
Remote IP Rating: IP67
