Marble Mosaic Waterjet Machine | Precision Stone & Tile Inlay AU

Model HEAD4020BA-5AC/HEAD42037Z-B
Working area 4000*2000 MM
Z-axis 150 MM
Cutting Accuracy ± 0.1 MM
Drive Type Servo
Repeat positioning accuracy ±0.05 MM
Pressure  420 MPA
Cutting Ability 150 MM
Auto Abrasive Supply System 200KG(optional:400KG/1000KG)
Pump type Intensifier
Max pressure 420Mpa(6000psi)
Working pressure 50-380MPa?7200-55000psi
Max orifice diameter 0.33mm
Water flow rate 3.7L/min
Maximum oil pump flow 119L/min
Pressure ratio 1:20
Main motor power 37KW(50hp)
Voltage 380v 50hz

?Overview?

Are you searching for the ultimate stone water jet cutting machine? Engineered to meet the demanding needs of Australian stonemasons, fabricators, and designers, this high-pressure waterjet cutter is the premier solution for projects requiring intricate detail and a perfect finish. Ideal for marble water cutting and creating custom tiles, our machine delivers unparalleled precision without the risk of cracks or heat damage.

This is more than just a machine; it's an investment in quality and capability, allowing you to produce everything from bespoke countertops to stunning water jet cut marble mosaic flooring. It is the definitive tool for anyone serious about stone water jet cutting.

?Key Features?

Ultra-High Pressure (UHP) System: Equipped with an industry-leading UHP pump (rated up to 60,000 PSI or higher) for powerful and efficient cutting through dense materials like granite and engineered stone.

High-Precision Cutting Head: Features a 5-axis dynamic head option, essential for creating complex bevels and compensating for taper, ensuring perfectly straight edges when cutting marble with water jet.

Intelligent CNC Control: A user-friendly interface that supports standard CAD files (DXF, DWG, etc.), making it easy to program intricate designs for mosaics and inlays.

Robust Gantry & Frame Construction: Built with a heavy-duty, stress-relieved steel frame to ensure maximum stability and long-term accuracy, critical for large stone slabs.

Automatic Abrasive Delivery System: Precisely meters the flow of garnet, ensuring a consistent and optimal cutting stream for the highest quality edge finish on stone and tile.

?Advantages & Applications: Ideal for Stone, Tile, and More?

Unmatched Stone & Tile Capability:

Stone & Ceramics: Master the art of stone cutting with a water jet. Our machine excels at cutting marble with water jet precision, creating custom countertops, vanities, and architectural elements. It is the perfect tool for producing intricate water jet cut marble mosaic designs and perfectly shaped water jet cut tiles from porcelain, granite, and ceramic.

Versatility Beyond Stone:

Metals: Stainless Steel, Aluminium, Titanium, Copper.

Glass: Including laminated and non-tempered decorative glass.

Composites: Carbon Fibre, Fibreglass, and more.

No Heat-Affected Zone (HAZ): The cold-cutting process is critical for stone and marble as it eliminates the risk of micro-fractures, discoloration, or structural stress, preserving the material's natural beauty and integrity.

Superior Edge Quality: Produces a smooth, finely-honed edge that often requires minimal to no secondary polishing, saving significant time and labour.

?Why Choose Us? | The Australian Advantage?

Australia-Wide Support: We have a local service team for fast-response technical support, maintenance, and training across Australia.

Professional Installation & Training: Our technicians handle complete on-site installation and provide comprehensive training focused on stone and tile cutting best practices.

Readily Available Spare Parts: Local parts inventory means minimising downtime and keeping your production running.
The floor-standing turnover platform is specially designed for cutting large stone materials. For ordinary cutting platforms, when loading and unloading materials, it is necessary to lift the stone slabs to a position one meter above the ground, which is time-consuming and laborious, and also likely to damage the slabs. The floor-standing turnover platform can perfectly solve these problems.

The turnover platform adopts a floor-standing form. The loading height is only 100mm. The loading process is simple and labor-saving, which improves the efficiency of loading and unloading.
Contact us today for a comprehensive quote and to discuss the water jet stone cutting machine price based on your specific configuration.
For More Details Please Contact : +48409
