Minimax S 41ES Elite 410 Planer

The technology packed minimax s 41es thicknessing planer for demanding craftsmen and carpentries. This machine offers an optimal planing experience with a 95mm diameter cutter block and 4 knives. It provides adjustable feed roller pressure, helicoidal profiled infeed roller, and a sandblasted steel outfeed roller for a perfect finish. The stability is ensured by a cast iron thicknessing table supported by 4 spindles. The “Xylent” spiralknife cutter block with 3 series of knives delivers exceptional results, reduced noise, improved dust extraction, and extended cutter block lifespan.

Additional Information
Perfect finish: An optimal planing with minimal effort, thanks to the 95 mm diameter cutter block and 4 knives. For an impeccable finish the pressure of the thicknesser feed rollers can be adjusted according to the type of wood machined. The roller infeed has a helicoidal profile to guarantee firm and constant work piece feed, while the outfeed roller in sandblasted steel maintains the perfect post-processing finishing.

Stability over time: For a maximum long lasting stability the cast iron thicknessing table lifts on 4 spindles with trapezoidal threazds dust protected.

“Xylent” spiralknife cutter block with 3 series of knives:
The 3 spiralknives give an exceptional finish. Reduced noise during machining provides a more comfortable working environment. It also improves the dust extraction due to the production of very small chips. Each cutter has 4 tips which can be rotated into the cutting position when worn. Therefore increasing the production life of the cutter block before knives require replacement.

TECHNICAL DATA
Cutterhead working width mm / inches 410 / 16
With XYLENT Spiral helical Cutterhead:
Cutterblock diameter / no° of standard knives
Dimension of standard knives mm / n°
mm 95 / 66
15 x 15 x 2.5
Max. stock removal mm 5
Jointer table length mm / inches 2200 / 86.6
Planer table dimensions mm / inches 410 x 775 / 16 x 30.5
Planer feed speeds /min 6 / 12
Min. – max. planer working height mm 3 – 240 / 0.12 – 9.5
Three-phase motor Hp 8
