Minimax SC 3C (2.6m) Panel Saw

The minimax sc 3 classic, the most compact sliding table saw for handling full-sized sheets. With a 2660mm sliding table stroke, it easily rips down 2400mm lengths, maximizing panel yield. Ideal for faced boards, it features a large crosscut fence, flip-over stops, and an oversized outrigger support table. With an aluminum sliding table, 300mm blade capacity, and scoring saw, it delivers precise performance. The 1270mm ripping capacity and scratch-free operation make it a reliable choice.

-Very high effective saw unit exhaust hood: the emission level is 90% lower with respect to the maximum level allowed by the European safety regulations!
-The sliding carriage ensures top quality precision, smooth and silent action, self-cleaning dustproof system, long lasting accuracy, no adjustments required.
-The sliding carriage is equipped with an additional table for the support of large dimensioned panels.
-The telescopic squaring rule is equipped with 2 flip-over stops which allow to have precise references that can be used for both profiles.
-The angular cutting device with flip-over stops allows to rapidly perform mitre cuts without moving the squaring fence and it is very useful for small work pieces
-Absolute precision and rapid positioning of the parallel fence which slides on a ground steel round bar
-Extruded aluminum fences with support and rapid locking guarantee maximum practicality.

Additional Information

Performance without limits
Incredible cutting of both very thick solid wood and panels, even those veneered, thanks to the new saw unit with a blade that has a maximum diameter of 315 mm that grants a 100 mm cutting height with the scoring blade installed.

Exclusive
Easier and more precise cutting is possible due to a perfectly stable support that is guaranteed, even for large work pieces, the wide sliding table and the large squaring frame fence provided as st+W30andard. Top quality precision, smooth and silent action, self-cleaning dustproof system, long lasting accuracy, no adjustment required.

The table
The table is made of extruded anodized aluminium with a closed honeycomb structure. The sliding table runs on an exclusive slideway system consisting of calibrated and hardened F550 SX

TECHNICAL DATA
Max. sawblade diameter mm / inches 315 / 12
Sawblade arbor size mm / inches 30 / 1.18
Max. sawblade projection from table at 90°/45° mm / inches 100/78 3.94/3.07
Cutting width on parallel fence (Rip capacity) mm / inches 1270 / 50
Max. squaring stroke of sliding table saw mm / ft 1600 / 5.5
Single-phase motor kW/Hp 2.2/3
