Max. working size (saw blade to 150mm) 300X 300mm
Distance from saw blade to worktable 3-200mm
Width of conveyor belt 285mm
Diameter of saw wheel 711mm
Feed speed 0-18m/min
Saw wheel elevation motor 0.18kw
Saw wheel motor 15kw
Hydraulic pressure 55kg/cm2
Dust outlet diameter 102mm x 2
Size of saw blade (LxWxH) 4572 x 27 x 0.9mm
4572 x 41 x 1.27mm
Saw kerf 1.2-2.2mm
Overall dimensions (LxWxH) 3000 x 2230 x 2050mm
Net weight 1800kg
