PT7000 5000kg Compression Load Cell

Brand: Australian Weighing Systems
Condition: Opened - never used
Weight: 10.00 kg
PT7000 5000kg Compression Load Cell - Heavy-Duty Alloy Steel - Industrial Weighing

Precision load cell designed for reliable force measurement in demanding industrial environments. Built for long life and accurate performance under heavy compressive loads.

Specifications:
• Model: PT7000
• Capacity: 5000 kg (5 Ton)
• Type: Compression Load Cell
• Output Signal: 2.0 mV/V
• Excitation Voltage: 5-15 V DC (typically 10 V DC)
• Material: Alloy steel, nickel-plated
• Protection Rating: IP67
• Mounting Style: Low-profile cylindrical

Key Features:
• Compact, rugged design suitable for harsh conditions
• High overload tolerance and excellent long-term stability
• Ideal for tank and hopper weighing, industrial scales, and process weighing systems
• Compatible with a wide range of indicators and PLCs

Typical Applications:
• Silo and vessel weighing
• Hopper scales
• Industrial press monitoring
• Structural load testing

Location: Morwell, VIC
Shipping: Australia-wide shipping available
