The SY18C is extremely powerful and demonstrates outstanding stability in all situations. With a robust design, efficient, powerful load-sensing hydraulic system and responsive, precise controls, this machine will have you smiling every time you turn the key.
Specifications
Dimensions
Operating mass: 1850 kg
Standard bucket capacity: 0.04 m³
Transport length: 3640 mm
Transport width: 980/1350 mm
Height over cabin/ROPS: 2420 mm
Engine
Rated power:14.6 kW/2400 rpm
Working Area
Max. digging depth: 2360 mm
Max. digging reach: 4000 mm
Min. swing radius : 1705 mm
Bucket digging force ISO: 15.2 kN
Arm digging force ISO: 9.2 kN
HYDRAULIC SYSTEM
Max. oil flow: 72 l/min
