Schechtl MAX 310 CNC Motorised Bending Machine

TWO TRUE EFFICIENCY PACKAGES. MAX AND MAB ARE IN
THE ELITE CLASS OF MOTORIZED BENDING MACHINES,
MAKING SURE YOU'RE ALWAYS AT THE FOREFRONT

MAX and MAB are favorites among sheet metal workers and exterior contractors.
This duo can handle a majority of all demands for sheet metal bending. A smart choice for guaranteed long-term success.

EXTREMELY EASY OPERATION
• incredibly simple startup: Set it up, plug it in, and you’re on your way!
• single-user operation results in real time savings
• movable foot switch is always in the right position
• bending beam’s soft start protects valuable surfaces

GETS TOP MARKS FOR PERFORMANCE AND SPEED
• offers very high bending capacity while keeping
energy costs low
• impressively short bending times thanks to an incredible
swivel speed of 90°/s and a 50mm/s opening speed for
the clamping beam
• faster bending process: if bending angle is less
than 90°, the clamping beam opens simultaneously
• high degree of production for sheet profiles on machines
with control system and motorized backgauge
DUAL ECCENTRIC SETS THE STANDARD FOR
STABILITY AND BENDING PERFORMANCE
• stable drive thanks to the solid welded
construction and highly rigid beam components
• MAX: bends sheet steel thicknesses up to 1.5mm (at 3,100mm)
• MAB: bends aluminum thicknesses up to 3mm (at 3,100mm)

• CNC S-Touch: high-resolution
touch-sensitive color display, intuitive
profile creation with profile-drawing,
sizing, and bending-sequence setting
all by fingertip, includes control of all
machine functions
• optional: PC offline software for
creating and editing profiles on the PC

CNC S-TOUCH CONTROL
Overall dimensions: Length mm 3,500
Width with 1,000 mm motorized back gauge 1,903mm
Working height 860mm
Total height 1,674mm
Weight 2,235kg

Connecting data
Connecting load 4.64kVA
Recommended fuse protection EU 3x slow blow 16
Connector plug CEE.. A 5-pole 16
Recommended RCD type DFS 4 B SK
Recommended RCD tripping current mA 30
Supply voltage EU 3 x AC 50 -60Hz

Optional Accessories
- 1 roller shear RSL (cutting capacity 0,80 mm steel)
- 1 pair of conical back gauge fingers CNC
only possible in conjunction with the standard back gauge without additional back gauge fingers
