Skyjack SJ9664 RT Scissor Lift

The Skyjack SJ9664 RT Scissor Lift is a heavy-duty, ultra high-reach access platform built for demanding outdoor and large-scale construction environments. Designed for maximum height, strength, and stability, it is ideal for projects requiring reliable elevated access at significant heights.

Powered by a Kubota diesel engine, the SJ9664 RT delivers dependable performance with Skyjack’s advanced AXLDRIVE™ 4WD system, providing excellent traction and control across rough and uneven terrain. With up to 32% gradeability and automatic levelling outriggers, the machine is engineered to handle challenging job site conditions with confidence.

With a 19.51m platform height and 513kg platform capacity, the SJ9664 RT provides safe and stable elevated access for tasks involving multiple operators, tools, and materials. Its oversized platform and dual 1.52m roll-out extension decks maximise workspace and improve productivity on site.

Specifications:
Max Working Height 21.51 m
Max Platform Height 19.51 m
Platform Length (Extended) 7.21 m
Platform Width 1.90 m
Platform Capacity 513 kg
Weight 9,997 kg
Overall Length 4.57 m
Overall Width 2.44 m
Stowed Height (Rails Up) 3.61 m
Stowed Height (Rails Down) 2.77 m
Ground Clearance 260 mm
Power Source Diesel
