Snorkel Guard™ secondary guarding system
Multi-function proportional controls
Zero tailswing
Tri-entry platform
Oscillating front axle
Power line to platform
Hour meter & on-board diagnostics display
Foam filled tyres
Tilt alarm
Horn
Drive motion alarm
Flashing amber light
Platform overload system
Specifications
Max Working Height 16.3 m
Max Platform Height 14.3 m
Max Outreach (horizontal) 7.35 m
Platform Size 1.0 x 1.83 m
Max Platform Capacity 227 kg
Weight 7,540 kg
Power Source Diesel Kubota V1505 24.9hp
Stowed Length 5.7 m
Stowed Width 2.1 m
Stowed Height 2.16 m
Ground Clearance 0.33 m
