Sound TIG 2240/M Pulse

POWERFUL & PROVEN
***INCREASE YOUR PRODUCTIVITY***
The new 220Amp 240V single phase Tig Sound AC-DC 2240/M has an exceptionally high power to weight ratio. It boasts 160A 100% duty cycle while weighing in at only 21.5kg.
Cebora’s attention to detail and being easy to use makes this machine stand out. The start current of just 5 Amps displays the machines ability for control and coupled with the tungsten balling system and pulse ensures great weld outcomes.

LEADING EDGE INVERTER TECHNOLOGY
is used to deliver exceptional pulse arc characteristics allowing the operator to achieve outstanding weld results on such a wide range of parent metals.

PULSE TIG
allows the operator to weld thin materials decreasing the heat affected zone on the parent metal and reducing metal fatigue adjacent to the weld.

THE ‘POWER FACTOR CORRECTION’
innovation is included on this machine enables the power source to tolerate supply/input voltage fl uctuations of +15% over voltage and -20% under voltage, protecting the power source from power spikes, drops and surges thus protecting the equipment and delivering consistent weld output.

TUNGSTEN BALLING SYSTEM
This new advance in AC Tig welding signifi cantly reduces the AC arc width giving the operator more control & delivering a petite weld bead without white oxidization either side of the weld.
How? a) sharpen a 2.4mm zirconiated tungsten to a pencil point b) program the machines tungsten balling system for the diameter ball needed i.e. 1mm c) start welding with new control!

SUITABLE FOR
Mild steel, Stainless steel, Aluminium, Copper & Brass

FEATURES
• 5-220 Amp AC/DC TIG
• 240V Single Phase
• Duty Cycle - 160A 100%
• Only 21.5kg
• Large 35-50 panel connectors
• 10 pin Amphenol plug for torch or remote foot control
• High Frequency Start
• Lift arc start option
• Pulse & pulse frequency adjustment.
• Digital amps and volts display
• AC Hertz adjustment to refi ne/narrow up the arc.50 Hz to 150 Hz
• AC Wave Balance adjustment for penetration & cleaning.
• Tungsten Balling System (TBS) for Aluminium Welding (see over page)
- sharpen your zirconiated tungsten to a point & program the machines tungsten balling system for the diameter ball needed. ie. you have a 2.4mm sharpened tungsten, set the diameter for a 1mm ball and start welding.
• Up slope & down slope/crater fi ll.
• Main weld current & background weld current adjustment.
• Pre gas & Post gas.
• Stored job memory facility.
• PFC (Power factor correction) System - Substantial energy savings with the ability to tolerate a wide fl uctuation in supply voltage (+15% / -20%).

OPTIONAL ITEMS
• Trolley (1656)
• Foot Control (193)
• Water Cooler (1341)
• Torches 4m, 8m, & 16m
• Torches water cooled or air cooled
