TANSHING TS-170 Manual Tailstock Specifications
Table Size: 170 mm
Center Height (Vertical): 135 mm
Overroll Height (Vertical): 225 mm
Center Bore Diameter: Ø35 mm (H7)
Width of T-Slot: 12 mm (H7)
Width of Guide Block: 18 mm (h7)
Base Length: 240 mm
Base Width: 97 mm
Total Width: 118.1 mm
Through-Hole Diameter: Ø35 mm
Clamping Torque: 490 N·m (50 kgf·m)
Net Weight: 25 kg
