GEDA 1500 Z/ZP – Heavy-Duty Transport Platform for Materials & Personnel

The GEDA 1500 Z/ZP is a powerful two-in-one construction hoist designed to operate as both a high-capacity material lift and a passenger transport platform. With dedicated control systems for each mode, it provides maximum flexibility for complex, multi-storey construction projects.

Material mode: lifts up to 2,000 kg at 24 m/min

Passenger mode: safely transports up to 7 people (500 kg) at 12 m/min

Built with a double mast system, the GEDA 1500 Z/ZP offers exceptional stability and smooth vertical travel, even when handling oversized or extremely heavy loads. Its modular platform system includes 14 different platform versions, allowing the hoist to be customised for a wide range of site layouts, access points, and material requirements.

Using the proven GEDA UNI-X-MAST system, compatible with GEDA hoists from 300 kg to 2,200 kg, the 1500 Z/ZP ensures long-term flexibility and ease of integration across fleets. With advanced corrosion protection and an automatic lubrication system, the 1500 Z/ZP is built for long service life under harsh site conditions.

Because this model is highly configurable, pricing is POA — contact us for a tailored quote based on your project requirements.

Key Features

Two systems in one: material hoist + passenger transport platform
High load capacity: up to 2,000 kg (materials) or 7 persons
Efficient lifting speeds: 24 m/min for materials, 12 m/min for passengers
14 modular platform versions – customisable for site-specific needs
Double mast system for enhanced stability with heavy or bulky loads
Uses the GEDA UNI-X-MAST system (300–2,200 kg compatibility)
Advanced corrosion protection for long-lasting durability
Automatic lubrication system reduces downtime and maintenance costs
Spacious platform designs for transporting large construction materials

Technical Specifications

Cargo Type: Persons & Materials
Mast System: GEDA UNI-X-MAST
Load Capacity (Materials): 2,000 kg
Load Capacity (Persons): 7 persons
Lifting Height: up to 100 m
Lifting Speed: 24 m/min / 12 m/min
Power Supply: 2 × 3.0 kW / 6.1 kW / 400 V / 50 Hz / 32 A

Optional Extras

Landing level safety gate “Comfort”
Landing level safety gate “Comfort Maxi” for oversized loads
Additional electric module
Fixing bracket sets for transport frames
Trailing cable guide for secure cable management
