Used Amada FOM23015NT Laser Cutting Machine

Second Hand Amada FOM2-3015 NT Laser Cutting Machine

The FOM2 3015 NT was developed at our manufacturing facility in Japan. It was designed after listening to customers who required a 4kW Laser and refused to compromise cut quality, machine accuracy, and machine expandability. Fabricators also wanted the ability to add automation later and not be forced to trade-up to another laser, thereby increasing their capital investment. Some of the FOM2's Key Benefits include:

4kW Resonator
Solid, Single Piece Cast Frame
High-Speed Cutting Head
Quick Change Nozzle and Focus Lens
Nozzle Cleaner and Calibration Plate
Power Save Function
AMNC-F PC Control
Upgradable to a Full Shuttle Table (Retrofit or with Purchase)
All Automation Options are Retrofittable

The FOM2 lasers combined the rock solid reliability the FO series is known for with increased capabilities and additional features such as reduced setup and secondary operations, increased throughput and consistency, a new resonator design and splatter free piece for better piecing of thick material. The FOM2 is Amada’s most versatile CO2 laser cutting machine.

Motion package
Travel method: X & Y – axis beam move
Drive method: X Rack & Pinion, Y & Z Ball screw
Work area
X= 121?
Y= 61?
Z= 7.87?
Maximum thickness
7/8? mild steel
1/2? stainless steel
3/8? aluminum
Maximum work weight: 2000 lbs
Rapid traverse
X & Y: 3,150 inches per minute
Simultaneous: 4455 inches per minute
Z: 2, 362 inches per minute
Repeatability: +/- 0.0002?
Z-axis sensor: HS-2007
CNC: AMNC PC-OS; windows embedded
Assist gas control: Automatic select
Oscillator: AF4000iB-4000 watt
Approximate machine weight: 34,216 lb. (includes shuttle tables)
Power requirements: 200/220V +/- 10% 50/60 Hz

CNC controller
Model: AMNC-NT
Display: LCD color graphics display
Control function
X,Y,Z-axis simultaneous and focus lens B-axis, adaptive optic and laser power control (CW, gated pulse, pierce routines, etc.)
Data input method: Touch screen, keyboard, ethernet, wireless, CD, USB, 3.5? floppy disk
Minimum command unit: 0.0001? (X,Y,Z)
Minimum travel unit: 0.0001? (X,Y,Z)
Standard memory: 2 MB
Operating modes: Automatic and manual
Display modes: Program contents, position information, program check, settings, parameters, beam diameter compensation, assist gas status, self-diagnostics
Interlock displays: Cooling water status, gas pressure status, vacuum status, turbo blower malfunction, shutter status beam power, resonator discharge, door open, WACS
