Volvo EC140DL Hydraulic Excavator - 105 hp Diesel, 6.03 m Dig Depth, 0.66 m³ Bucket Capacity

The Volvo EC140DL Hydraulic Excavator delivers strong digging performance, fuel efficiency and precision control for a wide range of earthmoving and construction tasks. Powered by a 3.77 L Volvo engine producing 105 hp, this 14-tonne machine provides reliable output while keeping operating costs low.

With an operating weight of 16,730 kg, the EC140DL balances lifting power and stability for safe, efficient operation. Its maximum digging depth of 6,030 mm and vertical wall digging depth of 5,460 mm make it well suited to foundation, trenching and general excavation work. The 0.66 m³ bucket and 3,500 kg lifting capacity offer excellent versatility on medium-scale projects.

The excavator’s hydraulic system (118 L/min maximum flow) delivers smooth and responsive control for demanding attachments. Built for durability, it features a tail swing radius of 2,200 mm, ground clearance of 436 mm, and track gauge of 1,990 mm, ensuring balance and mobility across rough or confined job sites.

Designed around Volvo’s proven reliability and operator comfort, the EC140DL includes easy-access service points, a spacious cab and precise hydraulic feedback, giving operators the confidence to perform at maximum efficiency day after day.

Key Features
- Engine Model: Volvo EC140DL (3.77 L Diesel, 105 hp)
- Main Hydraulic Flow: 118 L/min
- Operating Weight: 16,730 kg
- Bucket Capacity: 0.66 m³
- Lifting Capacity: 3,500 kg
- Maximum Digging Depth: 6,030 mm
- Vertical Wall Digging Depth: 5,460 mm
- Tail Swing Radius: 2,200 mm
- Ground Clearance: 436 mm
- Track Length: 3,760 mm
- Counterweight Clearance: 920 mm

Applications
- Civil construction and site preparation
- Trenching and pipe installation
- Landscaping and earthmoving
- Road and drainage projects
- Quarry and material handling operations
