AC system offers higher working efficiency
IP67 rated waterproof protection on AC wheel motors for longer lifespan
Lithium-ion batteries features long service life that the running time increases by 30%, and could apply to -20? cold working conditions
Work Height (lndoor/Outdoor) 10.00m/7.8m 32ft 10in/25ft 7in
A- Platform Height-Elevated (Indoor/Outdoor) 8.00m/5.8m 26ft 3in/19ft 0in
B - Platform Height -Stowed 1.26m 4ft 2in
C- Platform Length 2.30m 7ft 7in
D- Platform Width 0.81m 2ft 8in
Platform Extension 0.91m 3ft
E- Overall Height (Rails Up) 2.4m 7ft 11in
Overall Height (Rails Down) 1.9m 6ft 3in
F- Overall Length 2.49m 8ft 2in
G - Overall Width 0.81m 2ft 8in
H - Wheelbase 1.85m 6ft 1in
I- Ground Clearance (Stowed) 0.11m 4.5in
J- Ground Clearance (Raised) 0.02m 0.75in
Battery 135Ah Li-ion 135Ah Li-ion
Charger 24V/30A 24V/30A
Charger (option) 24V/60A 24V/60A
Gross 2090kg 4610lb
